SKU: 64026-LF
(0)

SIM-LED LED Module for Insight/Streamlight/EOTech M Series Light #64026-LF

Lumens Factory
Out of stock
$58.00

Secure checkout

Friendly support

Hassle-free returns

SIM-LED (Gen 5) LED Module for Streamlight/Insight/EOTech M2 UTL, M3, M3-LED, M4, M4-PRO, M5, M6 TLI

SIM-LED High Output Single Mode LED Tower Module, Generation 4
(6-9V Regulated Output)

Generation 2:
Upgraded to Nichia 319A, 5700K LED. Known for their superb pure white tint and high output. Great improvement from the previous version.

Generation 3:
New higher power driver circuit with wider input voltage, now able to use 2 x 3.7V rechargeable battery set ups (except for M6 TLI).

Generation 4:
New revised design on the aluminum base, now featuring anti-recoil spring allowing adjustable focus. Upgraded copper contact plates.

Generation 5:
Updated to Nichia 519A LED from Nichia 319A resulting in higher output and improved tint. (March, 2023)

-High Output Nichia 519A LED (Max Output 600 Lumens)
-6V-9V Regulated Output
-Maximum Current Output at 1200mA
-Cool White, Cool Colour Temperature (5700K)
-Direct Thermal Copper MCPCB
-Fully Potted Internal Components
-Reverse Polarity Input Protection
-Over-Discharge Protection
-Thermal Protection Warning
-Precision Machined Aluminum Lamp Assembly
-Every Lamp Assembly is Pre-Focused for the Ultimate Spot

Compatible with:

Insight / Streamlight / EOTech

M2 UTL (Universal Tactical Light), HK UTL (Universal Tactical Light), HK Universal Tactical Light MKII
M3
M3-LED (The model that use the CFL-700 incandescent lamp as main light source, NOT the model that use LED as main light source)
M4
M4-PRO
M5
M6 TLI (Tactical Laser Illuminator) (Do NOT use 3.7V rechargable batteries on the M6 TLI)

***NOT Compatible with M3X and M6X***
***NOT Compatible with lights that has been converted to LED with Streamlight's LED Conversion Kit***
***This module is ONLY compatible with incandescent versions of the lights in the compatibility chart***

Runtime:

2 x CR123A Primary Cells: ~2 hours
2 x 16340 (RCR123) 3.7V Rechargeable Cells: ~1.2 hours
***Do NOT use 3.7V rechargable batteries on the M6 TLI***

***Heat Warning: This is a high output LED module that produce excessive heat. Do not operate constantly for more than 20 mins to avoid overheating.***
